The locking screw concept was produced by Dr. Tepic S and Dr. Perren SM for the first time in 1995. With locking compression plate put in use, it became one of the most important developments for plate and screw internal fixation in recent years. Locking screws provide the ability to create a fixed-angle construct while utilizing familiar conventional plating techniques.
Important Fixation Concept: The fixed-angle construct functions like an internal fixator which maintains primary and secondary loss of reduction. This construct also provides improved fixation in osteopenic bone or multifragment fractures where traditional screw purchase is compromised. LCP constructs do not rely on plate-to-bone compression to maintain stability, ensuring the periosteum is protected and the blood supply to the bone is preserved.
| Product Name | Hot Selling Surgical Instrument set of Large Fragment Locking Plating System Orthopedic Instruments |
| Material | Ti-6AL-4V material, with MRI compatible |
| Color | Customized |
| Standard | ISO:13485/ISO:9001/CE |
| Brand | OEM / Customized |
| Screw | 5.0mm/6.5mm Locking Screw |
| Used | Bone fracture |
| Indication |
The LCP system applies to many different plate types and is therefore suitable for a large number of fracture types. Malunions, nonunions
Osteotomies
Fractures
|
| Features & Benefits |
The Combi-holes allow placement of conventional cortex and cancellous bone screw on one side or threaded locking screw on the opposite side of each hole.
Periarticular Plates are pre-contoured to create an anatomical fit that requires little or no additional bending that minimizes impinging on soft tissues.
Locking screw with stardrive recess.
Locking screw with self-tapping flutes.
The large core diameter improves bending and shear strength of the screw, distributing the load over a large area in the bone.
Special double lead thread beneath the screw head engages and locks into the threaded holes of the plate.
|
A medical device company founded in 1994, is now one of the largest designers, manufacturers, and suppliers of orthopedic implants and instruments. We have over 60,000 square meters of workshop. We are long term instrument contract manufacturer of top global orthopedic companies. Our own brand product lines include traumatology, spinal fixation system and surgical instrument, covering products such as femoral nail, titanium plates and screws, pedicle screw with rods, PEEK cage, balloon kyphoplasty for spine fracture and other instrument sets, already selling worldwide in Europe, Latin America, the Middle East and Asia.
Normally we send through courier, or post upon request from clients.
Yes, we are an ISO 9001:2008 and EN ISO 13485:2012 Certified Company. We have CE mark for many of our products.
We expect your minimum orders to be least at US$1000. However, we understand that customers need to place smaller samples orders in the beginning in order to test market our products. Samples against cost are available on request.
Of course you can, just send us pictures or samples. But this takes a little longer time for delivery.
Generally, we have stock for every listed products, which were produced monthly. But it depends on our sales condition. Better to ask our salesman for accurate inventory information.
All locking plating system components are strictly made from Ti-6AL-4V material, ensuring complete compatibility with MRI environments and optimal bone integration.
